2018 Lagoon 620

Olbia, IT

About

Specifications

  • Length: 62ft
  • Builder: Lagoon Catamarans
  • Beam: 32' 9"
  • Draft: 5' 0"
  • Year: 2018
  • Hull: Fiberglass
  • Status: Active

View More Specs

SPECS

  • Builder: Lagoon Catamarans
  • Designer: Van Peteghem and Lauriot-Prévost (VPLP)
  • Keel: Other

MEASUREMENTS

  • Length Overall: 62 ft
  • Max Draft: 5' 0"
  • Bridge Clearance Measure: 101' 9"
  • Beam Measure: 32' 9"

ENGINE(S)

  • Total Power: 300
  • Engine Brand: Volvo Penta
  • Engine Type: Inboard
  • Engine/Fuel Type: Diesel
  • Engine Hours: 1624
  • Engine Power: 150 hp

  • Total Power: 300
  • Engine Brand: Volvo Penta
  • Engine Type: Inboard
  • Engine/Fuel Type: Diesel
  • Engine Hours: 1431
  • Engine Power: 150 hp

TANKS

  • Fresh Water Tanks: 2 (650 Gallons)
  • Fuel Tanks: 2 (650 Gallons)

Accommodations

  • Number of cabins: 5
  • Number of heads: 5

Configuration

BASE

VERSION 5 CABINS, 5 HEADS – LATERAL GALLEY, 2 x 110 HP engines upgraded to 2×150 HP (Volvo D3-150)

INTERIOR WOOD

STANDARD INTERIOR WOOD IN ALPI WALNUT WITH ASBURGO FLOOR

UPHOLSTERY I CURTAINS

PLEATED BLINDS FOR AFT COMPANION WAYS

PLEATED BLINDS IN THE CABINS – 5 CABINS VERSION LATERAL GALLEY

PLEATED BLINDS IN THE SALON (In lieu of standard curtains on door & roller blinds on aft window)

SPECIAL UPHOLSTERY MARBLE (salon & settees)

SAILS RIGGING AND HARD

CODE 0 RIG AND POLE

LAZY BAG FOR ALUMINIUM BOOM

WHITE PAINTED ALUMINIUM CANOE BOOM WITH LED LIGHTS AND COVER

EXTERIOR UPHOLSTERY

COLOR OF EXTERIOR UPHOLSTERY AND CANVASES DARK GREY & GRAPHITE

AFT COCKPIT AND AFT BEAM CUSHIONS+ LOUNGER WITH ADJUSTABLE BACKREST – dark grey

BIMINI ON HELM STATIONS WITH LED LIGHTS – graphite

COCKPIT SIDES AND AFT SUN CANVAS+ SIDES AROUND AFT COCKPIT WITH WINDOWS – graphite

FLYBRIDGE CUSHIONS – dark grey

FOREDECK CUSHIONS – dark grey

KIT OF COVERS (Steering Wheels, wheel stations, cockpit tables, liferaft compartments)

SUNLOUNGERS ON FLYBRIDGE WITH ADJUSTABLE BACKREST – dark grey

DECK GEAR

2 LED SPOTLIGHTS IN AFT BEAM

2 MOORING CAPSTANS 1000W AFT PORT & AFT STARBOARD

4 ELECTRICAL WINCHES ON FLYBRIDGE IN LIEU OF STANDARD

4 UNDERWATER BLUE SPOTLIGHTS

2 BOARDING LADDERS

DECK COURTESY LIGHTS IN COCKPIT, TRANSOMS AND FLYBRIDGE

ELECTRICAL STEEL GRILL 220V IN COCKPIT LOCKER

FL YBRIDGE FLOOR IN TEAK

FLYBRIDGE FRIDGE (Steel interior. with top opening)

FORWARD DECK SENFRESH WATER WASH PUMP & AFT DECK FRESHWATER WASH PUMP

ICE MAKER 220V IN COCKPIT

RETRACTABLE HYDRAULIC GANGPLANK 2,5m / 8.20fl ON PORT TRANSOM

TENDERLIFT XL HYDRAULIC PLATFORM WITH REMOTE

ENGINE

ELECTRICAL BOW THRUSTER AT STARBOARD 24V 200KGF

ENGINES 2 x 150 HP (Volvo Penta 03-150)

EXTRA FOR ENGINE THROTTLE AT NAV STATION

PAIR OF 3-BLADES GORI FOLDING PROPELLERS FOR VOLVO D3-15(150HP)

ROPE CUTTERS ON THE PROPELLERS

ELECTRICAL CIRCUIT

ADDITIONAL SURGE PROTECTION

GEL BATTERIES 840Amp 24V

ONAN GENSET 19Kva 1500rpm 220V I 50HZ +COCOON+ FUEL TRANSFER PUMP

PACK FOR 2 BATTERY CHARGERS 220V 100Amp EACH

PACK FOR 2 INVERTERS 24 / 220V – 2 x 5000 VA

USB SOCKETS IN ALL CABINS

WATER CIRCUIT

EXTRA FOR INTEGRATED BIDET IN ELECTRICAL TOILET – 5-CABIN VERSIONS

WATER PURIFIER IN THE GALLEY

2 watermaker 400 L/H each – connected to boat engines working independently from the power generator

INTERIOR EQUIPMENT

2 BUNK BEDS AND DESK IN MIDDLE PORT CABIN

CREW CABIN IN PORT BOW COMPARTMENT (berth, sink, shower, toilet)

CREW CABIN IN STARBOARD BOW COMPARTMENT (berth)

DISH-WASHER MIELE 12 sets 220V

DOOR BETWEEN GALLEY AND SALON – LATERAL GALLEY VERSION

DOOR FOR DAYHEAD ACCESS TO MIDDLE PORT BATHROOM – alpi walnut

FANS 1N CABINS, GALLEY, AND SALON (8)

REVERSE CYCLE CHILLED WATER AIR CONDITIONING 96000 BTU

REVERSE CYCLE CHILLED WATER AIR CONDITIONING PORT BOW COMPARTMENT

REVERSE CYCLE CHILLED WATER AIR CONDITIONING STARBOARD BOW COMPARTMENT

WASHER / DRYER MIELE 5kg / 11 1bs 220V

WINE CELLAR IN LATERAL GALLEY (17 bottles)

HI-Fl & ELECTRONICS

2 B&G CAMERAS UNDER FLYBRIDGE

AIS 50B&G TRANSCEIVER WITH ANTENNA COUPLING

AUTOPILOT REMOTE B&G

B&G FORWARD SCAN SOUNDER

B&G RUDDER JOYSTICK AT NAV. STATION

EXTRA FDR ZM19 DISPLAY AT NAV. STATION, IN LIEU OF ZM16 DISPLAY

FUSION MS-RA7USB RADIO IN SALON+ 8 SPEAKERS (Salon, Cockpit& Fly) + REMOTE ON FLY

NAVIGATION PACK B&G 2017/2016

RADAR B&G BROADBAND 4G

RR MAST ANTENNA (TV, VHF, AM-FM, GSM)

TV LED 42″ PAUSECAM WITH ELECTRIC LIFT IN THE SALON – LATERAL GALLEY

VHF B&G RS90 DOUBLE HANDSET

EPIRB – GME MT603G 406MHZ GPS

ACCESSORIES

DINGHY SET OCEAN MASTER DELUXE 460 GREY WITH HONDA ENGINE BF60HP

BOAT CARE BOX

Full kitchen appliances + cooking utensils

SAFETY BOX + life rafts + life jackets

Standard 4 dock lines. 8 fenders, double anchor set + extra fenders/lines

CLEANING EQUIPMENT: Hydrojet cleaner, wet-dry cleaner, Dyson cordless vacuum cleaner

Boat and electronic manuals (Owner/User)

Equipment

Comfort

A/C and fans in all cabins and saloon, Electric toilets with integrated bidets, all WC/showers use freshwater, 60 HP tender, freshwater makers, water purifier (still/sparkling), hot water, USB and 220V sockets in all cabins and saloon, Bose Bluetooth Wi-Fi system, LED TV, BBQ, refrigerator/freezer with icemaker in cockpit area, wine cellar, gas stove, oven, Nespresso coffee machine, waffle iron, dishwasher, washer/dryer, cockpit showers with H/C water, hydraulic platform for sunbathing and diving fax/printer/scanner, hairdryer/straightener, iron, fridge on the flybridge, deck sunbed with cushions, bimini sun canopy, teak floors.

Navigation safety

B&G navigation system with radar, GPS plotter, autopilot, forward scanner, wind instruments, magnetic compass, VHF, AIS, cameras under flybridge, bow thruster, electric winches, electric windlass, life rafts, auto-inflatable life vests for all passengers, extinguishers, distress flares, first aid/medicine box, underwater lights.

General

19 kW power generator, 3 inverters 24/220V (2 x 5000 VA, 1 x 2000 VA), 840 Amp/24V gel battery set, 4 freshwater tanks, hydraulic gangplank.

2 x 400L/h freshwater makers – connected to the engines in order to work through a drive belt. One on port and one on starboard. They produce water while running, port side at minimum rpm and starboard side at cruising speed. That’s the reason of the difference in hours, because in the bay you can use the port to refill the tanks and to charge the batteries at the same time. Both water makers can obviously fill both sides, even at the same time having a production of 700/800 litres (together) per hour.

Tankage

• Fuel Tanks: 2
• Fuel Tank Capacity: 2 x 650 Lt (1300 Lt total) (344 US Gal)

• Water Tanks: 2
• Water Tank Capacity: 2 x 480 Lt (960 Lt. total) (254 US Gal)

• Holding Tank Count: 5 (1 tank per toilet)
• Holding Tank Capacity: 73 Lt (19 US Gal)

Engine and Generator hours January 2023

Port engine: 1624 h

Starboard engine: 1431 h

Generator: 1430 h

Of note – Conventional Lagoon boats typically use the generator more, because this is required for electric water-maker but not on this boat… It is not a charter boat and the generator is not needed in the same way to make water.

The TWO water-makers on this Lagoon 620 are connected directly to the 2 engines to produce water when using boat engines: more reliability and production capability (up to 800 l/hours). This is really important to ensure that you and your guests have nice holidays on the boat not being dependent on 1 generator and 1 water-maker (electric Lagoon water maker produce 280 l/h).

Disclaimer

Nicolle Associates offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.

  • This vessel is EU VAT not paid.
  • As always photographs do not do justice so a viewing is highly recommended.
  • This boat is lying in Olbia, Sardinia, Italy.
  • © 2023 Nicolle Associates
